What does the component do?
An image is a visual representation that is used to illustrate content, provide visual information or enrich the design.
When should the component be used?
- To visually support and enhance content.
- To present complex information or data graphically.
- To improve the visual appearance of the website or application.
- To generate user emotions or create a certain mood.
Rules
- Images should be used in high quality and appropriate resolution to ensure a clear and professional appearance.
- Use descriptive alt text for images to ensure accessibility and make sure the information is accessible to screen readers.
- Ensure that images are responsive and display well on different devices and screen sizes.
- Avoid excessive use of images so as not to unnecessarily increase the loading time of the website.
- Make sure that the image rights have been clarified and that no copyrights are infringed.
| Number | Type | Description | Optional | Info |
|---|---|---|---|---|
| 1 | Property | Image | No | |
| 2 | Text | Caption | Yes |
Playground
The sbb-image component is used to render an image.
Mainly from cdn.img.sbb.ch (with imageSrc), but we can set an external image too.
The size can be set with pictureSizesConfig.
<sbb-image image-src="..." alt="..."></sbb-image>
Usage
For image related elements, it is strongly recommended to wrap an sbb-image and all its related elements in a figure tag.
E.g. <figcaption> or <sbb-chip-label>.
<figure class="sbb-figure">
<sbb-image ...></sbb-image> or <img />
<figcaption>Caption / Copyright</figcaption>
</figure>
You can place overlapping content by using the sbb-figure-overlap-${horizontal-alignment}-${vertical-alignment} utility classes.
| Position | CSS class |
|---|---|
top-left | sbb-figure-overlap-start-start |
top-right | sbb-figure-overlap-start-end |
bottom-left | sbb-figure-overlap-end-start |
bottom-right | sbb-figure-overlap-end-end |
<figure class="sbb-figure">
<sbb-image ...></sbb-image>
<sbb-chip-label class="sbb-figure-overlap-start-start"></sbb-chip-label>
</figure>
Utility classes
Use the sbb-image-border-radius-${value} utility classes to set the image border radius.
| Border Radius | CSS class |
|---|---|
default | sbb-image-default |
none | sbb-image-none |
round | sbb-image-round |
<sbb-image class="sbb-image-border-radius-none"></sbb-image>
<!-- or -->
<img class="sbb-image-border-radius-round" />
Use the sbb-image-${ratio} utility classes to set the image aspect ratio.
| Aspect Ratio | CSS class |
|---|---|
free | sbb-image-free |
1-1 | sbb-image-1-1 |
1-2 | sbb-image-1-2 |
2-1 | sbb-image-2-1 |
2-3 | sbb-image-2-3 |
3-2 | sbb-image-3-2 |
3-4 | sbb-image-3-4 |
4-3 | sbb-image-4-3 |
4-5 | sbb-image-4-5 |
5-4 | sbb-image-5-4 |
9-16 | sbb-image-9-16 |
16-9 | sbb-image-16-9 |
<sbb-image class="sbb-image-16-9"></sbb-image>
<!-- or -->
<img class="sbb-image-4-3" />
Properties
| Name | Attribute | Privacy | Type | Default | Description |
|---|---|---|---|---|---|
alt | alt | public | string | '' | An alt text is not always necessary (e.g. in teaser cards when additional link text is provided). In this case we can leave the value of the alt attribute blank, but the attribute itself still needs to be present. That way we can signal assistive technology, that they can skip the image. |
complete | - | public | boolean | Whether the image is finished loading or failed to load. | |
customFocalPoint | custom-focal-point | public | boolean | false | Set this to true, if you want to pass a custom focal point for the image. See full documentation here: https://docs.imgix.com/apis/rendering/focalpoint-crop |
decoding | decoding | public | 'sync' | 'async' | 'auto' | 'auto' | If the lazy property is set to true, the module will automatically change the decoding to async, otherwise the decoding is set to auto which leaves the handling up to the browser. Read more about the decoding attribute here: https://developer.mozilla.org/en-US/docs/Web/API/HTMLImageElement/decoding |
focalPointDebug | focal-point-debug | public | boolean | false | Set this to true, to receive visual guidance where the custom focal point is currently set. |
focalPointX | focal-point-x | public | number | 1 | Pass in a floating number between 0 (left) and 1 (right). |
focalPointY | focal-point-y | public | number | 1 | Pass in a floating number between 0 (top) and 1 (bottom). |
imageSrc | image-src | public | string | '' | Right now the module is heavily coupled with the image delivery service imgix and depends on the original files being stored inside AEM. You can pass in any https://cdn.img.sbb.ch img src address you find on sbb.ch to play around with it. Just strip the url parameters and paste in the plain file address. If you want to know how to best work with this module with images coming from a different source, please contact the LYNE Core Team. |
importance | importance | public | 'auto' | 'high' | 'low' | 'high' | The importance attribute is fairly new attribute which should help the browser decide which resources it should prioritise during page load. We will set the attribute value based on the value, we receive in the loading attribute. 'eager', which we use for the largest image within the initial viewport, will set the attribute value to 'high'. 'lazy', which we use for images below the fold, will set the attribute value to 'low'. |
loading | loading | public | 'eager' | 'lazy' | 'eager' | With the support of native image lazy loading, we can now decide whether we want to load the image immediately or only once it is close to the visible viewport. The value eager is best used for images within the initial viewport. We want to load these images as fast as possible to improve the Core Web Vitals values. lazy on the other hand works best for images which are further down the page or invisible during the loading of the initial viewport. |
performanceMark | performance-mark | public | string | '' | With performance.mark you can log a timestamp associated with the name you define in performanceMark when a certain event is happening. In our case we will log the performance.mark into the PerformanceEntry API once the image is fully loaded. Performance monitoring tools like SpeedCurve or Lighthouse are then able to grab these entries from the PerformanceEntry API and give us additional information and insights about our page loading behaviour. We are then also able to monitor these values over a long period to see if our performance increases or decreases over time. Best to use lowercase strings here, separate words with underscores or dashes. |
pictureSizesConfig | picture-sizes-config | public | string | '' | With the pictureSizesConfig object, you can pass in information into image about what kind of source elements should get rendered. mediaQueries accepts multiple Media Query entries which can get combined by defining a conditionOperator. Type is: stringified InterfaceImageAttributesSizesConfig-Object An example could look like this: { "breakpoints": [ { "image": { "height": "675", "width": "1200" }, "mediaQueries": [ { "conditionFeature": "min-width", "conditionFeatureValue": { "lyneDesignToken": true, "value": "sbb-breakpoint-large-min" }, "conditionOperator": false } ] }, { "image": { "height": "549", "width": "976" }, "mediaQueries": [ { "conditionFeature": "min-width", "conditionFeatureValue": { "lyneDesignToken": true, "value": "sbb-breakpoint-small-min" }, "conditionOperator": false } ] }, { "image": { "height": "180", "width": "320" }, "mediaQueries": [ { "conditionFeature": "max-width", "conditionFeatureValue": { "lyneDesignToken": true, "value": "sbb-breakpoint-micro-max" }, "conditionOperator": "and" }, { "conditionFeature": "orientation", "conditionFeatureValue": { "lyneDesignToken": false, "value": "landscape" }, "conditionOperator": false } ] } ] } |
skipLqip | skip-lqip | public | boolean | false | If set to false, we show a blurred version of the image as placeholder before the actual image shows up. This will help to improve the perceived loading performance. Read more about the idea of lqip here: https://medium.com/@imgix/lqip-your-images-for-fast-loading-2523d9ee4a62 |
Events
| Name | Type | Description | Inherited From |
|---|---|---|---|
error | Event | Emits when the image loading ended in an error. | |
load | Event | Emits when the image has been loaded. |
CSS Properties
| Name | Default | Description |
|---|---|---|
--sbb-image-aspect-ratio | auto | Can be used to override aspectRatio property. This way we can have, for example, an image component with an aspect ratio of 4/3 in smaller viewports and 16/9 in larger viewports. |
--sbb-image-object-fit | cover | Can be used to set the object-fit CSS property of the image itself if the image itself is cropped. |
--sbb-image-object-position | Can be used to set the object-position CSS property of the image itself if the image itself is cropped. |
