Was macht die Komponente?
Die Paginator-Komponente ermöglicht die Navigation durch grosse Mengen von Inhalten, indem sie die Inhalte in mehrere Seiten unterteilt. Er zeigt Benutzer:innen an, auf welcher Seite man sich befindet und bietet Steuerungselemente zum Wechseln zwischen den Seiten.
Wann soll die Komponente eingesetzt werden?
- Wenn eine große Anzahl von Einträgen oder Inhalten effizient verwaltet werden muss.
- Wenn eine Alternative zu unendlichem Scrollen benötigt wird.
Regeln
- Bei geringer Anzahl von Seiten kann eine alternative Lösung wie "Mehr laden" anstelle eines Paginators in Betracht gezogen werden.
| Nummer | Typ | Beschreibung | Optional | Hinweis |
|---|---|---|---|---|
| 1 | Komponente | Zurück- und Vorwärts-Buttons | Nein | |
| 2a | Komponente | Seite, aktiv | Nein | |
| 2b | Komponente | Seite | Nein | |
| 3 | Label | Ja | ||
| 4 | Komponente | sbb-select | Ja |
The sbb-paginator is a component which provides navigation for content split across multiple pages,
e.g. a table with many rows.
It can be controlled via the following properties:
length: the total number of items being paged;pageSize: the number of items per page (default:10);pageIndex: the index of the current displayed page (default:0).
<sbb-paginator length="100" page-size="20"></sbb-paginator>
By default, a sbb-mini-button-group with two buttons is displayed,
which allows moving to the previous/next pages.
The positioning of this element relative to the page numbers is set using the pagerPosition property (default: start):
<sbb-paginator length="100" page-size="20" pager-position="end"></sbb-paginator>
Users have the possibility to dynamically change the page size using a dropdown menu;
to do this, consumers must add the pageSizeOptions property, which accepts an array of number
that are set as sbb-option's values within a sbb-select.
Consumers must be consistent, so the defined pageSize must be an element of the pageSizeOptions array.
The dropdown menu and the previous / next buttons are facing each other with the page numbers always in the center.
<sbb-paginator length="100" page-size="20" page-size-options="[10, 20, 50]"></sbb-paginator>
States
The component can be disabled by using the disabled property.
<sbb-paginator length="100" page-size="20" disabled></sbb-paginator>
Style
The component has two size, named s and m (default).
<sbb-paginator length="100" page-size="20" size="s"></sbb-paginator>
Events
Consumers can listen to the page event on the sbb-paginator component to intercept the page change event.
The event.detail contains both the information about the pageIndex and the previousPageIndex,
as well as the length and the pageSize.
Accessibility
The component has role="group" to semantically group its child controls;
consumers should add an appropriate aria-label attribute with a text
that describes the content controlled by the paginator.
<sbb-paginator aria-label="Select page" length="100" page-size="20"></sbb-paginator>
Properties
| Name | Attribute | Privacy | Type | Default | Description |
|---|---|---|---|---|---|
accessibilityItemsPerPageLabel | accessibility-items-per-page-label | public | string | '' | Accessibility label for the items per page. Defaults to Items per page.. Can be set for cases like a carousel, where slide or image fits better. |
accessibilityNextPageLabel | accessibility-next-page-label | public | string | '' | Accessibility label for the next page. Defaults to next page. Can be set for cases like a carousel, where slide or image fits better. |
accessibilityPageLabel | accessibility-page-label | public | string | '' | Accessibility label for the page. Defaults to page. Can be set for cases like a carousel, where slide or image fits better. |
accessibilityPreviousPageLabel | accessibility-previous-page-label | public | string | '' | Accessibility label for the previous page. Defaults to previous page. Can be set for cases like a carousel, where slide or image fits better. |
disabled | disabled | public | boolean | false | Whether the component is disabled. |
length | length | public | number | 0 | Total number of items. |
negative | negative | public | boolean | false | Negative coloring variant flag. |
pageIndex | page-index | public | number | 0 | Current page index. |
pagerPosition | pager-position | public | 'start' | 'end' | 'start' | Position of the prev/next buttons: if pageSizeOptions is set, the sbb-select for the pageSize change will be positioned oppositely, with the page numbers always in the center. |
pageSize | page-size | public | number | 10 | Number of items per page. |
pageSizeOptions | page-size-options | public | number[] | [] | The available pageSize choices. |
size | size | public | 'm' | 's' | 'm' / 's' (lean) | Size variant, either m or s. |
Methods
| Name | Privacy | Description | Parameters | Return | Inherited From |
|---|---|---|---|---|---|
firstPage | public | Move to the first page if not already there. | void | SbbPaginatorCommonElementMixin | |
hasNextPage | public | Whether there is a next page. | boolean | SbbPaginatorCommonElementMixin | |
hasPreviousPage | public | Whether there is a previous page. | boolean | SbbPaginatorCommonElementMixin | |
lastPage | public | Move to the last page if not already there. | void | SbbPaginatorCommonElementMixin | |
nextPage | public | Advances to the next page if it exists. | void | SbbPaginatorCommonElementMixin | |
numberOfPages | public | Calculates the current number of pages based on the length and the pageSize; value must be rounded up (e.g. length = 21 and pageSize = 10 means 3 pages). | number | SbbPaginatorCommonElementMixin | |
previousPage | public | Move back to the previous page if it exists. | void | SbbPaginatorCommonElementMixin | |
selectPage | public | Move to a specific page index. | index: number | void | SbbPaginatorCommonElementMixin |
Events
| Name | Type | Description | Inherited From |
|---|---|---|---|
page | CustomEvent<SbbPaginatorPageEventDetails> | The page event is dispatched when the page index, length or page size changes. | SbbPaginatorCommonElementMixin |
